CNMG 431-LM GM1115

Superior performance in stainless steel medium turning at high speeds

• Lower cutting forces with high edge sharpness
• Precision micro-edge geometry optimized for stainless steel
• Sophisticated edgeline reduces work hardening
• Very wide application range
• GM1115 is a triple-coated MT-CVD grade, on a gradient-sintered substrate with excellent wear resistance and outstanding adhesion properties
• Post-coating treatment provides smoother cutting zone interface for reduced built-up edge and longer tool life
• Best suited for stable conditions and high cutting speed applications

Item Specifications

• ISO Description
  CNMG 120404-LM GM1115
• Insert Shape
  C – 80° Diamond
• Insert Size d (IC)
  1/2
• Edge Length l
  .508
• Thickness s
  3/16
• Corner Radius r
  1/64
• Chipbreaker
  LM – Medium Turning Stainless
• Grade
  GM1115 – CVD for Stainless
• Cutting Speeds, ft/min
  820 (660-980)
• Feed per Rev, inches
  .006 (.003-.012)
• Depth of Cut, inches
  .070 (.016-.187)
